Key Features:
Supports 8 IP camera inputs (plug‑and‑play)
Smart AI analytics: Facial recognition, perimeter protection, Motion Detection 2.0, AcuSearch
Decoding capability:
With AI on: up to 2 ch @ 12 MP, or 3 ch @ 8 MP, or 6 ch @ 4 MP, or 12 ch @ 1080p
Without AI: up to 20 ch @ 1080p
Dual video outputs:
HDMI up to 4K @ 30 Hz
VGA up to 1080p @ 60 Hz
Bandwidth: 80 Mbps incoming, 160 Mbps outgoing
Storage: 2 SATA bays (up to 10 TB each, 20 TB total)
PoE (on /8P model): Eight RJ45 ports, supports 802.3af/at (≤ 80 W total)
Audio I/O: 1 channel each input/output
Alarm I/O: 4 inputs, 1 output
Remote access: Up to 128 concurrent connections; ONVIF Profile S/G; supports RTSP, SMTP, SNMP, iSCSI, DDNS, HTTPs, NFS, and more
Power: 12 V DC, 3.3 A (≤ 15 W without HDD or PoE)
Operating range: –10 °C to +55 °C, humidity up to 90% non-condensing
Form factor: 1U rack-mount (≈ 385 × 315 × 52 mm), weight ≈ 1 kg without HDD
1‑Year Warranty included
